Vircell VirClia – Powerful Automation System

Last updated: 07th September, 2018

The Virclia® system it is a small automated platform that will serve as the ideal complementary system for those esoteric and low volume tests. To improve turn around time and the efficiency in your laboratory.

VirClia® benefits include:

  • Kits are supplied in a monotest format with ready-to-use reagents

  • Simultaneously run 1 to 24 tests

  • Cost effective use of consumables

  • Dual reader: VirClia® Monotest & ELISA plates

  • Pipetting directly from primary sample tubes and use of different size tubes

  • Improve workflow and turnaround time

  • Determination of esoteric parameters

  • More than 80 references available



Sample Capacity 192 patient sample positions
Test Tube Size(s) Standards 12, 13 or 16 x 75 mm tubes (custom racks also available)
MTP Positions 2 positions
Pre-dilution MTP Positions 1 position
Well-Tracking Independent well tracking and timing
Wash bottles 2 external wash bottles
Probe/Needle Single probe, dual needle
Dispense Volume Up to 500 µl
Aspiration Volume 1 µl
Incubation Temperature Up to 40 ºC
Photometer Wavelenghts 405, 450, 490, 550 and 630 nm wavelengths standard (Custom wavelengths available)
Chemiluminescence Photomultiplier Tube (PMT)  Detection type: glow, Spectral range: 300-500 nm, Dark count: 50 counts per second (standard), Measuring time: 200 ms (adjustable 1 to 1000 ms), Dynamic range: 6 decades (optional add-on).
Orbital MTP Shaker  Amplitude: 1mm, Speed: Up to 900 RPM, Capacity: 3 MTP (2 reaction, 1 pre-dilution).
Power Supply 120-265V, 50-60Hz
Dimensions  W: 64 cm, D: 57 cm, H: 45 cm (W: 25.2 in, D: 22.5 in, H: 17.7 in)
CE Listed Yes
